A pipeline is a sequence of stages, and between every pair of stages an artifact sitting in an S3 bucket. Understand that one sentence and the rest of CodePipeline is configuration.
The model
- Stage — a named step: Source, Build, Deploy. Stages run in order
- Action — the work inside a stage. Actions in a stage can run in parallel or in a declared order
- Artifact — a zip file in the pipeline's S3 bucket. Each action declares what it consumes and what it produces
The artifact bucket is the part worth internalising, because most confusing pipeline failures are really artifact failures. Nothing is passed in memory: the build stage writes a zip, the deploy stage reads it, and if the names do not line up the stage fails with very little explanation.
Source from GitHub, without a token
Use a CodeConnections connection rather than a personal access token. A token is a long-lived credential in your account that someone must rotate; a connection is authorised once and revocable from either side.
aws codeconnections create-connection \
--provider-type GitHub --connection-name github-folaulauThe connection is created PENDING and must be completed in the console — the CLI
cannot finish the handshake. Nothing using it works until the status is AVAILABLE,
and a pipeline whose source stage fails immediately after creation is usually this.
A pipeline, in outline
{
"name": "stayhub",
"stages": [
{
"name": "Source",
"actions": [{
"name": "Checkout",
"actionTypeId": {
"category": "Source", "owner": "AWS",
"provider": "CodeStarSourceConnection", "version": "1"
},
"outputArtifacts": [{ "name": "SourceOutput" }],
"configuration": {
"ConnectionArn": "arn:aws:codeconnections:us-west-2:111122223333:connection/abc",
"FullRepositoryId": "folaulau/stayhub",
"BranchName": "main"
}
}]
},
{
"name": "Build",
"actions": [{
"name": "Build",
"actionTypeId": {
"category": "Build", "owner": "AWS",
"provider": "CodeBuild", "version": "1"
},
"inputArtifacts": [{ "name": "SourceOutput" }],
"outputArtifacts": [{ "name": "BuildOutput" }],
"configuration": { "ProjectName": "stayhub-build" }
}]
}
]
}Note how SourceOutput is produced by one action and named as an input by the next.
That string is the whole contract between stages.
The failure that wastes an afternoon
An input artifact name that does not match an earlier output. The pipeline fails at the consuming stage with a message about the artifact not being found, and because the stage that "failed" is not the one that is wrong, people debug the build.
Two related versions of the same problem:
- An action can consume artifacts only from earlier stages, so reordering stages breaks the chain silently
- CodeBuild only uploads what its
artifactsblock declares. A build that produces files and declares nothing hands the next stage an empty zip, which then fails at deploy rather than at build
aws codepipeline get-pipeline-state --name stayhub \
--query "stageStates[].[stageName,latestExecution.status,actionStates[].latestExecution.errorDetails.message]"Manual approval
An approval action pauses the pipeline until a human approves it in the console, and it can post to an SNS topic so somebody knows it is waiting.
It is the cheapest way to get a controlled production release, and there are two things worth
knowing. The approver needs codepipeline:PutApprovalResult, which is not in most
read-only policies. And an approval times out after seven days and the pipeline
then fails — so an approval requested before a holiday quietly expires.
CodePipeline or GitHub Actions
Worth being honest, because for most small projects the answer is not CodePipeline.
| Use | When |
|---|---|
| GitHub Actions | Your code is on GitHub, the deploy target is AWS, and you want the pipeline defined in the repository next to the code. Simpler, faster to iterate, and free for public repositories |
| CodePipeline | You need the pipeline itself governed by IAM and CloudFormation, cross-account deploys with role assumption, or an audit trail in CloudTrail. Common in regulated environments |
This site uses GitHub Actions with OIDC to assume a deploy role, which removes both the stored credential and the extra service. CodePipeline earns its place when the release process itself is something auditors ask about.
Variables and passing values between stages
Actions can export variables that later stages read, which is how a build tells a deploy what image tag it just pushed without writing it into a file:
aws codepipeline get-pipeline-execution \
--pipeline-name stayhub --pipeline-execution-id abc-123 \
--query "pipelineExecution.artifactRevisions[].[name,revisionId]"A CodeBuild action exports whatever its buildspec declares under exported-variables,
and a later stage references it as #{BuildAction.IMAGE_TAG}. The namespace matters —
each action declares one, and a reference to an action with no namespace set resolves to nothing
rather than failing loudly.
Triggering and re-running
aws codepipeline start-pipeline-execution --name stayhub
aws codepipeline retry-stage-execution --pipeline-name stayhub \
--stage-name Deploy --pipeline-execution-id abc-123 \
--retry-mode FAILED_ACTIONSretry-stage-execution re-runs only the failed stage with the artifacts it already
has, which is much faster than rebuilding from source after a transient deploy failure — and it is
the command most people do not know exists.
By default a pipeline triggers on every push to the configured branch. That is usually what you want for a deploy to staging and rarely what you want for production, which is what the manual approval gate above is for. Triggers can also be filtered by branch, tag or changed file path, so a monorepo does not run every pipeline on every commit.
Where the pipeline itself lives
A pipeline clicked together in the console is a pipeline nobody can recreate, and it is the same failure that makes people adopt infrastructure as code everywhere else. Define it in CloudFormation or Terraform and the release process becomes reviewable — a change to how production is deployed arrives as a pull request rather than as something one person did on a Thursday.
It also gets you the thing CodePipeline is genuinely good at: the pipeline is an AWS resource, so IAM governs who may change it and CloudTrail records who did.
